Pagid OEM front brake disc. Part number 54599NHC. Brembo equivalent 09.A820.11.
| Brand | Pagid |
|---|---|
| Range | OEM quality |
| Axle | Front |
| Brake Disc Type | vented |
| Inner Diameter (mm) | 153.6 |
| Outer Diameter (mm) | 314 |
| Brake Disc Thickness (mm) | 24.9 |
| Minimum thickness (mm) | 23 |
| Height (mm) | 52.2 |
| Hole arrangement / number | 05/06 |
| Bolt hole circle (mm) | 112 |
| Centering Diameter (mm) | 68 |
| Wheel Bolt Bore Diameter (mm) | 15.3 |
| Supplied without | without wheel bearing without wheel hub without wheel studs |
| Surface | Coated |
| Processing | High-carbon |
| Weight (kg) | 8.4 |
| EAN | 4007590354472 4007590391729 |
| Packaging size (L x W x H, cm) | 32.8 x 32.8 x 7.5 |
OE numbers are the original equipment references this part replaces. The Brembo number shows the Brembo part it is equivalent to. Always confirm fitment for your vehicle before ordering.
Equivalent part numbers from other brands
Brembo09.A820.11
Original equipment (OE) numbers
AUDI8K0615301, 8K0615301T, 8W0615301G, 8W0615301T, 8WD615301, L8K0615301, L8KD615301, L8WD615301
AUDI (FAW)8K0615301, 8K0615301T, 8W0615301T, 8WD615301, L8K0615301, L8KD615301, L8WD615301
SEAT8K0615301, 8W0615301G, 8W0615301T
SKODA8K0615301, 8W0615301G, 8W0615301T
VW8K0615301, 8W0615301G, 8W0615301T
VW (FAW)L8WD615301
Numbers are given for reference so you can check this part against the one you have or against another brand. Always confirm fitment for your vehicle before ordering.
